Tempo NC-100 Netcat Micro Voice / Data / Video Wiring Tester ** Not Compatible with Power Over Ethernet PoE Devices **

Netcat micro voice / data (Cat 5e/Cat 6) / video tester
For a POE tester see TPS100C
For an upgraded version that is compatible with POE, see NC500
One 9 volt battery required - not included
Brand name(s) : Tempo Communications

*** NOT COMPATIBLE WITH POWER OVER ETHERNET (POE) DEVICES ***
If the tester is connected to a POE powered Cat 5 / 6 patch cable , VOLTS! will appear permanently - not repairable , tester will no longer work correctly.

Features:
- Tests shielded twisted pair (STP), unshielded twisted pair (UTP) and coaxial cables
- TIA/EIA standard wiring pair verification
- Detects shorts, opens, reversed polarity, crossed and split pairs
- Generates three distinct, selectable digital tone patterns for cable tracing and troubleshooting - Tracing modes can be adjusted for high performance LAN cables
- Complete set of connector types standard (telephone, LAN and coax)
- Nested remote allows end-to-end testing of all wiring types
- Simple testing of LAN wiring and phone lines
- Detection of common wiring and connector errors
- Warning of hazardous voltages
- Checks for reversed telephone wires

Backlight : Green LED
Battery : 9 V Alkaline Battery (PP3)
Buttons : Four Momentary Contact Push Button
Depth : 33.000 MM
Display LCD : Icon And Seven Segment Type
Frequency Rating : 577 HZ And 983 HZ
Humidity : 0 To 95 PCT Non-Condensing
Interface Connections : RJ45 Shielded Socket, RJ12 6-Way Socket, F-Type Threaded Female Coaxial Connectors
Length : 150.000 MM
Minimum Cable Length : 2.000 To 3.000 MR (5.000 To 10.000 FT)
Pair Tracing Tones : Alternating Frequencies Of 577 HZ And 983 HZ Are Produced At Three User Selectable Rates
Standard : TIA/EIA
Storage/Operating Temperature : -10 To 60 DEG C0 - 50 DEG C
Sub Brand : NETcat
Type : Micro Digital Voice Data And Video Wiring
Weight : 220.000 GM Including Remote Unit And Battery
Width : 70.000 MM
