NTE LED 5mm 4-LEAD Tricolour LED Red/Green/Blue NTE30115

NTE30115 LED Tri Color

5mm Super Fresh Red/Super Green/Super Blue

Features:

RoHS Compliant

Water Clear

Absolute Maximum Ratings:

(TA= +25°C unless otherwise specified)

Power Dissipation, Pd

Green & Blue : 120mW

Red : 100mW

Continuous Forward Current, IF : 25mW

Peak Forward Current (1/10 Duty Ratio, 0.1ms Pulse Width), IFM

Green & Blue : 100mA

Red : 50mA

Reverse Voltage, VR

Green & Blue : 4V

Red : 5V

Operating Temperature Range, Topr : −25°C to +80°C

Storage Temperature Range, Tstg : −20°C to +90°C

DIP Soldering Temperature (During Soldering, 3mm from body, 5sec max), TL : +260° 25mW

Peak Forward Current (1/10 Duty Ratio, 0.1ms Pulse Width), IFM

Green & Blue : 100mA

Red : 50mA

Reverse Voltage, VR

Green & Blue : 4V

Red : 5V

Operating Temperature Range, Topr : −25°C to +80°C

Storage Temperature Range, Tstg : −20°C to +90°C

DIP Soldering Temperature (During Soldering, 3mm from body, 5sec max), TL : +260°C
