BAE LED 10mm Super Bright Blue Water Clear Lens, 8500mcd@20ma 3.3V Max

Manufacturer Part# NTE30070 (BULK)

NTE30065 thru NTE30071

Super Bright LED Indicators, 10mm

Features:

RoHS Compliant

All Plastic Mold Type w/Water Clear Lens:

NTE30065 (Yellow Green, AIInGaP/GaAs)

NTE30066 (Light Green, InGaN/GaN)

NTE30067 (Orange, AllnGaP/GaAs)

NTE30068 (Light Red, AllnGaP/GaAs)

NTE30069 (Deep Red, GaAlAs/GaAlAs)

NTE30070 (Blue, INGaN/GaN)

NTE30071 (Super White, GaInN/GaN))

Absolute Maximum Ratings:

(TA= +25°C unless otherwise specified)

Reverse Voltage, VR

NTE30066, NTE30070, NTE30071 4V

NTE30065, NTE30067, NTE30068, NTE30069 5V

Continuous Forward Current, IF

All Devices : 25mA

NTE30066 : Only 30mA

Peak Forward Current (1.10 Duty Cycle, 0.1ms Pulse Width), IFM

NTE30065, NTE30067, NTE30068, NTE30069 50mA

NTE30066, NTE30070, NTE30071 100mA

Electrostatic Discharge (HBM, NTE30071 Only), ESD 150V

Power Dissipation, PD :

NTE30065, NTE30067, NTE30068 : 100mW

NTE30069 : 110mW

NTE30066, NTE30070, NTE30071 : 120mW

LED Junction Temperature, Tj : +100°C

Operating Temperature Range, Topr

All Devices : -25°C to +85°C

NTE30071 : Only -40°C to +85°C

Storage Temperature Range, Tstg

All Devices : -40°C to +100°C

NTE30067 Only : -25°C to +100°C

Lead Temperature (During Soldering, .063 (1.6mm) from body, 5sec max), TL : +260°C
