Jensen Iso-Max VRD-1FF 75 Ohm Digital Cable TV Isolation Transformer

Cable TV - 75 Ω CATV or VHF/UHF capacitive based isolator eliminates audio and video system hum. Wide 'notch-free' response will not drop channels. F connectors, compatible with analog and digital cable. Note: this unit will NOT work with satellite systems
Manufacturer: Jensen Transformer


Features:
Primary application: Isolating cable TV from home AV system
Bandwidth: 2 MHz to 1300 Mhz Insertion loss: 0.19 dB @ 5 Mhz, 0.01 dB @ 50 Mhz
VSWR:< 1.2
Standard connector: F connector on both ends

The Iso•Max VRD-1FF is a high performance capacitive based isolator that has been meticulously designed to break the ground loop that causes hum and buzz in audio and 60 cycle hum bars in video.

Improves audio/video quality by reducing 60 Hz ground currents
2 MHz to 1300 MHz bandwidth spans VHF/FM/UHF/CATV spectrum
Capacitive based design minimizes broadcast channel interference
Meets FCC Part 76 Regulations for CATV systems

Housed in a compact cylinder and designed for use with RG59 or RG6 type cable, this second generation VRD-1FF employs a unique RF engineered solution that delivers a ruler-flat response from 2 Mhz to over 1300 MHz spanning the VHF/FM/UHF and CATV spectrum. The VRD-1FF's exceptionally linear response prevents frequency dips that can cause channels to drop out in digital cable. Gold plated F connectors are carefully machined to ensure true 75 Ω compatibility for optimal signal integrity while minimizing reflections and ghosting.

Plug and play easy to use, this passive solution doesn't require any power. One simply inserts the VRD-1FF in series with the incoming signal and it quietly goes to work without degrading the signal. This makes the VRD-1FF a 'must have' for the AV technician that is servicing and installing digital cable as well as conventional CATV or VHF/UHF antenna or MATV systems. Important Note: The VRD-1FF is NOT suitable for use with RG11 cable or as an isolator for satellite dish systems.
