Circuit-Test CFA128025LS 12VDC Sleeve Bearing Fan 80mm x 80mm x 25mm 30CFM 24dB 1.8W 0.15A 2100RPM 3 Wire

Fan 12VDC, 80mm x 25mm, 30 CFM, Sleeve Bearing

Locked Rotor Alarm Signal Output (yellow wire lead): Under normal conditions a locked rotor alarm signal outputs a constant signal frequency... if the fan stops spinning or "locks", it then outputs a "LOW" condition signal. If the fan starts spinning again, the "LOW" condition signal will go away.

Features:

Dimensions: 80 x 80 x 25mm (3.15 x 3.15 x 1")

Mounting Center: 71.5mm (2.82")

Rating: 12VDC

Current: 0.15 Amps

Power: 1.8 W

Bearing: Sleeve

Speed: 2100 RPM

Noise: 23.7 dBA

Max Air: 30 CFM

Max Pressure: 2.18 mmH2O

Temperature: -10 to +70 C

Hours: 20000-30000

Termination: Wire leads

Weight: 85g

Impeller: Glass fibre reinforced plastic 94V-0 PBT

Frame: Glass fibre reinforced plastic 94V-0 PBT
